L-Band Directional Coupler DC + 10Mhz Pass – 20DB
£60.00
20dB L-band (850-2150MHz) directional coupler. Input & through ports are DC & 10MHz pass. Coupled port is DC & 10MHz block. The max current rating is 3A. Applications: Typical fields of applications are telecom infrastructures, satellite systems, microwave links, test and instrumentation and radar networks.
Description
20dB L-band (850-2150MHz) directional coupler. Input & through ports are DC & 10MHz pass. Coupled port is DC & 10MHz block. The max current rating is 3A.
Applications: Typical fields of applications are telecom infrastructures, satellite systems, microwave links, test and instrumentation and radar networks.
Additional information
| Connector | 50 ohm BNC, 50 ohm N-Type, 50 ohm SMA, 75 ohm BNC, 75 ohm F-Type |
|---|---|
| Freq. Low | 850 |
| Freq. High | 2150 |
| Freq. Unit | MHz |
| Max. Current | 3A |
| IP Rated | Yes |
| Dc block | No |
| Partial DC Pass | Yes |
| 10MHz Pass | No |
| 10MHz Block | No |
| Partial 10MHz pass | Yes |
| Bias | Passive |
| Coupling factor (dB) | 20 |
